This manual covers safety precautions and proper installation of the Samsung XQBM30-88 washing machine, including leveling, placement away from heat sources, and correct connection of power, water inlet, and drain hoses. It also explains how to secure the isolation panel and remove transport packaging to prevent abnormal noise.
The guide details the operation of the machine, describing each washing program (standard, mixed‑soak, quick, wool), how to select water level and start or pause cycles, and provides troubleshooting tips and product specifications such as power consumption, capacity, dimensions, and spin speed. This manual is written in Chinese.
| Rated power consumption | 215 W |
|---|---|
| Rated washing capacity | 3.0 kg |
| Dimensions (W×D×H) | 450 mm × 540 mm × 768 mm |
| Rated spin capacity | 3.0 kg |
| Product weight | 26 kg |
| Standard water consumption per cycle | 28 L |
| Water pressure range | 0.05–0.78 MPa |
| Standard water usage | 79 L |
| Spin speed | 880 rpm |
| Washing method | 波索式 |
Place the machine on a level floor, keep it away from direct sunlight and heat sources, use a grounded three‑pin outlet, unplug the power cord when not in use, and avoid touching the control panel with sharp objects.
Press the slider down, detach the old hose, align the new hose with the inlet connector until you hear a click, then tighten the connection with a screwdriver in a clockwise direction.
