This manual provides detailed instructions on how to use the embroidery machine, including overview, electrical control components and icon interface introduction, how to start simple embroidery, how to input patterns, how to select patterns for embroidery, how to set the starting point of patterns, how to check the embroidery range of patterns, how to quickly locate a needle in a pattern, how to change colors, cutting threads, lifting speed operation, point back to zero (100°), moving the embroidery frame, how to open the pattern, how to carry out matching embroidery, patch embroidery and circular embroidery, how to repair embroidery, pattern management, etc., to help users use the embroidery machine correctly.
The document begins with an overview and safety precautions, describing required protective measures, power‑off procedures, and environmental conditions for safe use of the control system. It also details installation requirements such as grounding, voltage specifications, and workspace clearances.
Subsequent sections cover the system’s user interface, function modules, parameter settings, and detailed operation steps for needle positioning, color change, and automatic stitching. Appendices list parameter tables, fault diagnostics, and maintenance tips. This manual is written in Chinese.
| Frequency | 50 Hz / 60 Hz |
|---|---|
| Maximum power capacity | 10 kW (up to 10 kW for larger machines) |
