This is an instruction manual for an embroidery machine. It introduces the various parts and functions of the embroidery machine, as well as how to use the embroidery machine to embroider
The document outlines safety precautions, proper installation environment, and handling of the control system, emphasizing the need to disconnect power before servicing and to avoid exposure to hazardous conditions. It also describes the system’s interface components, USB connections, and indicator lights.
Detailed sections cover operation steps, parameter settings, memory management, color change procedures, and fault diagnosis, with tables for troubleshooting and parameter initialization. The manual concludes with appendices listing common errors and maintenance tips. This manual is written in Chinese.
| Operating temperature range | -40 °C to 30 °C |
|---|---|
| Relative humidity range | 30 % – 95 % |
| Ground wire size | ≥ 4 mm² |
Power must be disconnected before opening the chassis, and all internal components remain energized even after power cut, so avoid touching them.
The system can operate from –40 °C up to 30 °C.
Relative humidity should be kept between 30 % and 95 %.
