This document provides instructions and guidelines for using an electronic embroidery machine, including the introduction of electronic control components and graphical user interface, the steps for simple embroidery, pattern input and selection, color change, thread cutting, moving the embroidery frame, as well as pattern management and disk management functions.
The manual begins with safety precautions, emphasizing that only qualified personnel should service the equipment, power must be disconnected before opening the case, and the environment must be free of moisture, dust, and flammable gases. It also details grounding requirements and the proper handling of magnetic components.
Subsequent sections describe the control components, interface panels, thread management, parameter settings, troubleshooting procedures, and maintenance tasks. Appendices include error codes, replacement part information, and quick reference tables. This manual is written in Chinese.
| Minimum operating temperature | -40°C |
|---|---|
| Relative humidity range | 30% - 95% |
The system can operate down to –40 °C and requires a relative humidity between 30 % and 95 %.
