The STPS15L30CB is a 2A low voltage power Schottky rectifier suitable for switch Mode Power Supply and high frequency DC to DC converters. Packaged in DPAK, this device is intended for use low voltage, high frequency inverters, free-wheeling and polarity protection applications.
The STPS15L30CB is a low‑drop Schottky rectifier designed for high‑frequency switch‑mode power supplies, DC‑DC converters and free‑wheeling applications. It is offered in a DPAK package with a dual center tab for easy thermal management.
The document lists key electrical ratings such as a 30 V repetitive peak reverse voltage, 7.5 A average forward current and 75 A surge current, as well as thermal data including a 4 °C/W junction‑to‑case resistance and a maximum junction temperature of 150 °C. Mechanical dimensions, package weight and ordering information are also provided.
| Repetitive peak reverse voltage (VRRM) | 30 V |
|---|---|
| Maximum junction temperature (Tj) | 150 °C |
| Junction‑to‑case thermal resistance (Rjc) | 4 °C/W |
| Forward voltage drop at 7.5 A (typ.) | 0.48 V |
| Package type | DPAK |
The device is rated for a repetitive peak reverse voltage of 30 V.
The maximum operating junction temperature is 150 °C.
It is supplied in a DPAK (dual‑center‑tab) package.
The typical forward voltage drop at 7.5 A is 0.48 V.
