This manual provides the complete instructions for the Midea CXW‑180‑DS21 kitchen range hood. It includes safety warnings, warranty conditions, and step‑by‑step guidance for installing the exhaust duct, mounting the unit, and connecting the power supply. Detailed cleaning and maintenance procedures are described to keep the fan, oil cup, and safety net in good condition.
The document also lists the technical specifications of the product, such as power supply, motor power, airflow, dimensions and required installation height. Troubleshooting tips for common abnormal phenomena (e.g., motor not running, excessive noise, oil cup full) are provided along with contact information for Midea’s after‑sales service. This manual is written in Chinese.
| Model | CXW-180-DS21 |
|---|---|
| Power Supply | 220V~/50Hz |
| Exhaust Duct Diameter | 650–750 mm |
| Dimensions (L×W×H) | 720 mm × 510 mm × 407 mm |
The safety net should be cleaned at least once every two weeks, but not less frequently than once a month, to prevent oil buildup.
The unit must be connected to a 220 V, 50 Hz power supply that matches the local voltage and frequency requirements.
