This document is the user manual of a power module. It introduces the characteristics, uses and performance of the power module.
The PAC/PAV series from Moore Industries converts AC current or voltage inputs to highly accurate outputs (±0.25%). It is designed for monitoring and measuring power consumption of loads such as motors, heaters, transformers, and generators, and includes surge protection and dust‑proof aluminum housing.
This manual covers product description, performance specifications, selection guidelines, wiring, installation, calibration, and maintenance procedures. It also lists the various input/output ranges, configurations (single‑phase, three‑phase, self‑powered, external‑powered), and environmental limits. This manual is written in Chinese.
| Output accuracy | 0.25 % |
|---|---|
| Insulation voltage | 2000 Vrms |
| Power consumption (self‑powered PAC) | 0.3 VA |
| Operating temperature range | -20 °C to +70 °C |
| Response time | <0.2 s |
The output accuracy is 0.25 %.
It has an insulation capability of 2000 Vrms.
It operates from –20 °C to +70 °C.
The response time is less than 0.2 seconds.
