Featured Moore manuals

Moore Industries HIM Smart HART Loop Interface and Monitor User Manual

User Manual 25 pages · 1.3 MB · ZH

The HIM Smart HART Loop Interface and Monitor is a HART‑compatible device that can acquire up to three independent HART variable signals and provide digital monitoring, alarm, and fault detection. It connects to a 4‑20 mA loop and can be integrated with DCS, PLC or other control systems.

The manual covers physical installation on DIN rails, wiring, power requirements, Modbus RTU communication settings, LED status indicators, EMC compliance, and safety grounding. It also includes specifications, fault codes, and a troubleshooting guide to help users configure and maintain the device. This manual is written in Chinese.

Covers: Introduction · Features · Specifications · Installation · Operation · LED Indicators

Latest Moore manuals

• MOORE Workshop Vernier Caliper 100 Series Manual

  This file provides detailed information on two Moore-And-Wright workshop vernier calipers.

• MOORE INDUSTRIES PAC PAV alternating current / Voltage convertor Manual

  This document is the user manual of a power module. It introduces the characteristics, uses and performance of the power module.

• MOORE INDUSTRIES IPX Explosion-Proof Field-Mount Current-to-Pressure Transmitter

  Moore Industries' IPX Explosion-Proof, Field-Mount Current-to-Pressure Transmitter is the ideal solution when accurate I/P conversion must be reliably made in harsh field environments. Its rugged, extruded aluminum explosion-proof housing can be installed in nearly any location. The IPX accepts a 4-20mA or 10-50mA input and converts it to a proportional pneumatic output signal (3-15 psig, 0.2-1 bar, 20-100kPa, etc.) for controlling valves, actuators, and other pneumatic devices. The IPX can be surface-mounted or affixed to a 2-inch pipe horizontally or vertically, and offers both standard and metric conduit entry ports.

• MOORE INDUSTRIES IPT-DIN Current-to-Pressure Transmitter

  The IPT-DIN Current-to-Pressure Transmitter accepts a 4-20mA input signal and is capable of supplying a 3- 15psig (or 15-3psig) pneumatic output signal, as well as a number of other pneumatic signals typically used in I/P-type process control applications.

• MOORE INDUSTRIES HIT/HIX HART signal Isolators Manual

  The document introduces an intelligent transmitter that supports 4-20mA and HART signal output, and has an emergency stop system and multiple size options.

• MOORE INDUSTRIES IPH Field-Mount Current-to-Pressure Transmitter

  This document introduces Moore Industries' IPH Field-Mount Current-to-Pressure (I/P) Transmitter. The product features a compact and versatile mounting bracket, making it suitable for harsh field environments. It meets NEMA 4X and IP65 requirements, being watertight, dust-tight, and resistant to corrosion and chemicals. The IPH can reduce installation costs by using electrical wiring instead of pneumatic tubing. It can be mounted in any position without affecting performance. The product is vibration resistant and has RFI/EMI protection.

• Moore Industries HIM Smart HART Loop Interface and Monitor User Manual

  User Manual 25 pages · 1.3 MB · ZH

  The Moore Industries HIM Smart HART Loop Interface and Monitor User Manual provides installation, operation, specifications, and troubleshooting details for…
