The IPT-DIN Current-to-Pressure Transmitter accepts a 4-20mA input signal and is capable of supplying a 3- 15psig (or 15-3psig) pneumatic output signal, as well as a number of other pneumatic signals typically used in I/P-type process control applications.
The IPT‑DIN Current‑to‑Pressure Transmitter accepts a 4‑20 mA input and provides a 3‑15 psig (or 15‑3 psig) pneumatic output for I/P‑type process control. Housed in a compact 40 mm wide aluminum case, it can be snapped onto a DIN rail or a Moore Industries pneumatic header rack for high‑density installations.
Features include plug‑in connections, vibration resistance, self‑sealing valves, and optional accessory air filters. The unit offers infinite resolution, up to 1.4 SCFM output volume, and low air consumption. Optional intrinsic‑safety versions and waterproof enclosures are available, and a front‑panel red LED indicates the presence of the input signal.
| Input signal | 4‑20 mA |
|---|---|
| Pneumatic output range | 3‑15 psig (or 15‑3 psig) |
| Air capacity | 1.6 SCFM |
| Output span | Fully adjustable to 100 % |
| Accuracy | < 0.5 % of span |
| Step response | 0.3 seconds into 100 ml |
| Supply pressure effect | Maximum 0.3 % / 1.4 psig |
| Ambient temperature range | -40 °C to +85 °C |
| Weight | 20 ounces (0.57 kg) |
| Dead‑ended air consumption | 0.08 SCFM |
It accepts a standard 4‑20 mA current loop input.
The unit can be snapped onto a DIN rail using a pneumatic mounting block or onto a Moore Industries pneumatic header rack; optional removable terminal block allows tool‑free removal.
Yes, intrinsically safe units are offered as an option and are certified by CSA, ATEX, and other standards.
The red LED lights when an electrical input signal is present.
