LinkLEDtm RGB is a modular red, green and blue light engine, which enables OEMs to easily construct full colour change applications using LED technology.
The LinkLED RGB is a modular red, green and blue light engine designed for OEMs to create full‑colour lighting applications. It features plug‑and‑socket connections, a thermal‑adhesive backed PCB for direct metal mounting, and high‑flux LED technology for deep saturated colours.
Typical applications include signage, back‑lighting, decorative effects, fibre‑optic light engines, light pipes, cove and cornice lighting, and architectural or furniture illumination. The module operates up to 75 °C PCB temperature and offers a lamp life of 50 000 hours.
| Absolute Maximum PCB Temperature | +75 °C |
|---|---|
| Recommended Maximum PCB Temperature | +55 °C |
| Lamp Life at 55 °C PCB | 50,000 hours |
| Power Consumption – Red LED | 1 W |
| Power Consumption – Green LED | 1.2 W |
| Power Consumption – Blue LED | 1.2 W |
| Maximum Current | 350 mA |
| Module Dimensions | 55 × 25 × 8 mm |
| Finish | Black solder resist |
| Connector Type | 4‑Way CT Connector |
| Typical Lumen Maintenance | 70 % at 50,000 hours |
The absolute maximum PCB temperature is +75 °C.
The red LED consumes 1 W, while the green and blue LEDs each consume 1.2 W.
The module measures 55 mm × 25 mm × 8 mm.
It uses a 4‑Way CT Connector.
