JAE Europe has announced the DP1, an external connector for the DisplayPort digital video and audio interface that supports high bandwidth services, such as high definition video, on PCs and home entertainment systems. The DP1 connector is a shielded 20-pin connector featuring a 0.5mm pitch, providing a robust fitting and accurate positioning during equipment assembly.
The DP1 series from JAE provides a 20‑pin, shielded external connector for the DisplayPort digital video and audio interface. It features a 0.5 mm pitch and a robust surface‑mount design with metal solder pins and a plastic snap‑in pin for accurate positioning.
The connector supports high‑bandwidth services, offering up to 10.8 Gbit/s transmission, 1080p video over 15 m cables, and multiple lane configurations (1‑4 lanes). JAE also supplies standard and latching cable assemblies in 2‑ and 3‑metre lengths. This manual is written in Chinese.
| Number of pins | 20 |
|---|---|
| Pin pitch | 0.5 mm |
| Maximum data rate | 10.8 Gbit/s |
| Connector type | Standard and latching formats |
The DP1 connector has 20 pins.
The pin pitch is 0.5 mm.
It supports up to 10.8 Gbit/s transmission rate.
