The LT6010 is an operational amplifier that combines low noise and high precision input performance with low power consumption and rail-to-rail output swing. It has features such as maximum offset voltage of 35µV, maximum input bias current of 110pA, supply current of 135µA, rail-to-rail output swing, and minimum voltage gain of 120dB. The LT6010 is suitable for applications such as thermocouple amplifiers, precision photodiode amplifiers, instrumentation amplifiers, and battery-powered precision systems.
The LT6010 precision op‑amp combines low noise and high‑accuracy input performance with low power consumption and rail‑to‑rail output swing. It features a maximum offset voltage of 35 µV, input bias current of 110 pA, and a typical supply current of 135 µA.
Designed for single‑supply operation, it operates from 2.7 V to 36 V and works over an temperature range of –40 °C to 85 °C. Typical applications include thermocouple amplifiers, precision photodiode amplifiers, instrumentation amplifiers, and battery‑powered precision systems. The device is available in SO‑8 and 3 mm × 3 mm DFN packages, with dual and quad versions (LT6011, LT6012).
| Maximum Offset Voltage | 35 µV |
|---|---|
| Maximum Input Bias Current | 110 pA |
| Supply Current (normal operation) | 135 µA |
| Supply Current (shutdown) | 12 µA |
| Rail‑to‑Rail Output Swing | within 40 mV of either rail |
| Supply Voltage Range | 2.7 V to 36 V |
| Operating Temperature Range | –40 °C to 85 °C |
| Minimum Voltage Gain | 120 dB |
| Input Noise Voltage Density | 14 nV/√Hz |
The LT6010 has a maximum input offset voltage of 35 µV.
It draws 135 µA of supply current under normal conditions.
The device operates from –40 °C to 85 °C.
Yes, its output swings within 40 mV of either supply rail.
