H61MXL Series Motherboard User Manual, introduces the function and use of the motherboard.
This manual covers the H61MXL Series motherboard, detailing its specifications, layout, and back‑panel connectors. It includes safety notices, environmental compliance information, and a full list of supported components.
The guide walks users through hardware installation (CPU, memory, expansion cards), BIOS setup, system monitoring, and software utilities such as FOX LiveUpdate, FOX LOGO, and FOX DMI. It also provides troubleshooting tips and contact information for technical support. This manual is written in Chinese.
| CPU socket | LGA1155 |
|---|---|
| Chipset | Intel H61 |
| Memory slots | 2 x 240‑pin DDR3 DIMM, up to 16 GB |
| Expansion slots | 1 x PCI Express x16, 1 x PCI Express x1 |
| SATA ports | 4 x SATA 2.0 (300 MB/s) |
| Network controller | Atheros AR8151 Gigabit Ethernet |
| Audio codec | Realtek ALC662 (HDA, 2/4/5.1‑channel) |
| USB ports | 10 x USB 2.0 (6 rear, 4 board) |
| Form factor | Micro ATX (22.6 cm × 17.3 cm) |
It uses an LGA1155 socket for Intel CPUs.
The board supports ten USB 2.0 ports—six on the back panel and four on the board.
Up to 16 GB of DDR3 memory can be installed.
An Atheros AR8151 Gigabit Ethernet controller is integrated.
