This manual introduces the features and characteristics of the S3C2500B 32-bit RISC microprocessor, including pin definitions, timing information, control registers, interrupt system, memory management, on-chip peripherals, and software interfaces.
This manual introduces the Samsung S3C2500B 32‑bit RISC microprocessor, covering its product overview, key features, block diagram, package diagram, pin assignment, and signal description. It also details special registers and provides a high‑level view of the device architecture.
The document continues with the programmer's model, describing ARM/Thumb state handling, memory formats, instruction lengths, data types, operating modes, registers, exception handling, and a complete instruction set reference. Mechanical data, including the 272‑pin BGA package dimensions, are presented at the end of the manual.
| Architecture | 32‑Bit RISC Microprocessor |
|---|---|
| Revision | Revision 1 |
| Package Type | 272‑pin BGA (272‑BGA‑2727‑AN) |
It is available in a 272‑pin BGA package (272‑BGA‑2727‑AN).
The manual covers Revision 1 of the S3C2500B.
The S3C2500B is manufactured by Samsung Electronics.
