The FRENIC 5000VG7S series is a high‑performance vector‑control frequency converter designed for a wide range of industrial drives such as cranes, injection molding machines, and production lines. It offers advanced control functions, multiple communication options, and compliance with international standards.
The converter includes self‑tuning during motor stop, position control, load‑vibration suppression, and various protection features. It supports RS485 (38.4 kbps) as standard and optional fieldbuses like Profibus‑DP, DeviceNet, Interbus‑S, Modbus‑Plus, and CANopen. The unit is available in 200 V and 400 V versions covering 0.75 kW to 400 kW motor capacities. This manual is written in Japanese.
| Speed control accuracy | 0.005 % |
|---|---|
| Speed response | 100 Hz |
| Current response | 800 Hz |
| Linearity | 3 % |
| Input voltage | 200 V / 400 V |
| Maximum output frequency | 0 – 105 Hz |
| RS485 communication speed | 38.4 kbps |
Yes, the unit has a self‑tuning function that can execute motor parameter self‑tuning during motor stop.
