The document is about 3.7KW inverters. It contains the characteristics of inverters, including rated output power, output voltage, output current, output frequency, torque limit, inverter model, brand and other information
This document describes the FRENIC‑Mini series frequency transformer, covering safety precautions, installation steps, wiring diagrams and basic operation. It explains how to set frequency, voltage, and control parameters using the built‑in vector control method.
The manual also details optional accessories, RS485 communication setup, compliance with IEC standards, and provides contact information for Fuji Electric worldwide support. This manual is written in Japanese.
| Rated Power (Single‑phase) | 0.1 kW – 2.2 kW |
|---|---|
| Rated Power (Three‑phase) | 0.4 kW – 3.7 kW |
| Communication Interface | RS485 |
| Ingress Protection | IP20 |
| Cooling Method | Natural air cooling |
The single‑phase version is rated from 0.1 kW to 2.2 kW, and the three‑phase version from 0.4 kW to 3.7 kW.
Yes, the device includes an RS485 communication interface.
The enclosure complies with IP20 protection.
