VIPer50A-E/ASP-E is an integrated high-voltage, high-power MOSFET PWM controller featuring adjustable switching frequency, soft start and shutdown control, automatic burst mode operation, internally trimmed zener reference, undervoltage lockout with hysteresis, integrated start-up supply, over-temperature protection, low standby current and adjustable current limitation.
The VIPer50A‑E/ASP‑E is a high‑voltage SMPS controller integrating a 700 V, 1.5 A vertical power MOSFET and a current‑mode control circuit. It features adjustable switching frequency up to 200 kHz, soft‑start, burst‑mode standby, and over‑temperature protection.
The datasheet provides electrical ratings, pin descriptions, typical application circuits, thermal data, and layout guidelines. It also includes ordering information and revision history for reference.
| Maximum Current | 1.5 A |
|---|---|
| Supply Voltage (Vpp) | 5 V to 15 V |
| Power Dissipation (25 °C) | 60 W |
| Storage Temperature | -65 °C to 150 °C |
| Thermal Resistance (J‑C) | 1.9 °C/W |
| Thermal Resistance (A‑C) | 60 °C/W |
In standby, total power consumption is less than 1 W, meeting the “Blue Angel” norm.
The component can be stored from –65 °C up to 150 °C.
