LC-4522 is a dot matrix printer produced by Canon. This document is its user manual.
This manual covers everything needed to install and operate the Star Micronics LC-4522 dot matrix printer. It includes detailed steps for unpacking, setting up the printer, installing the platen knob, ribbon cassette, and paper guides, as well as connecting the printer to a power outlet and a computer.
Later chapters describe control‑panel functions, EDS mode settings, MS‑DOS printing, and paper‑handling procedures such as loading fanfold paper, manual sheet feeding, and clearing paper jams. Safety warnings and maintenance tips are also included.
| Paper types | Fanfold, single sheets |
|---|---|
| Power rating | as indicated on printer label |
Unplug the printer, open the front cover, carefully pull the jammed paper out, and adjust the release lever or platen knob if needed.
Follow the loading fanfold paper procedure (see page 12) to insert the fanfold stack, adjust the paper guide, and engage the automatic feeder.
