This document is a quick start guide for Jabra® GO™ 6470, providing contact information for assistance in Europe, Asia, and the Americas.
The document explains the architecture of a portable ultrasound system, covering front‑end AFE, beamforming modules, back‑end processing and power‑consumption considerations. It highlights how FPGA families such as Virtex‑6, Spartan‑6 and the 7 series enable flexible, low‑cost implementations.
Key topics include interface requirements, channel counts, ADC/DAC specifications, and the role of FPGA in reducing NRE cost and accelerating development. The note also provides a disclaimer regarding safety‑critical applications. This manual is written in Chinese.
| Supported FPGA families | Virtex‑6, Spartan‑6, 7 series |
|---|---|
| Channel count range | 8–128 channels |
| ADC sample rate | 30 MSPS (12‑bit) |
| Transducer drive voltage | 3 V–300 V |
Virtex‑6, Spartan‑6 and the 7 series FPGAs are supported.
A 12‑bit ADC operating at 30 MSPS is used.
The transducer operates from 3 V up to 300 V.
