The HI-5042, HI-5043, HI-5047, HI-5049, HI-5051 CMOS Analog Switches are a family of CMOS analog switches that offer low resistance switching performance for analog voltages up to the supply rails and for signal currents up to 80mA.
The HI‑504X/HI‑505X family of CMOS analog switches offers low ON resistance and high current capability (up to 80 mA) for analog voltages up to the supply rails. The devices feature break‑before‑make switching, TTL/CMOS compatibility, and very low leakage currents (0.8 nA at 25 °C).
The datasheet includes functional descriptions, ordering information for various packages (CERDIP, SOIC, PDIP), absolute maximum ratings, detailed electrical specifications, test circuits, and package dimension drawings for both small‑outline plastic and ceramic dual‑in‑line frit‑seal packages.
| ON resistance (typical) | 50 Ω for HI‑5042‑HI‑5047, 25 Ω for HI‑5049‑HI‑5051 |
|---|
