ADuC816 is a MicroConverter® with embedded Flash MCU and dual-channel 16-bit ADCs. It features high-resolution Sigma-Delta ADCs, programmable gain front end, and various built-in peripherals.
The ADuC816 is a 16‑bit dual‑channel sigma‑delta ADC microconverter that integrates an 8051‑compatible MCU, on‑chip Flash/EE program and data memory, a 12‑bit DAC, current sources, and various serial interfaces. It is designed for low‑power intelligent sensor applications such as weigh scales, pressure transducers, and 4‑20 mA transmitters.
The device operates from a single 3 V or 5 V supply, consumes as little as 3 mA in normal mode and 20 pA in power‑down, and is packaged in a 52‑lead MQFP. Detailed specifications cover ADC resolution, reference accuracy, timing, power consumption, and peripheral functions.
| Flash Program Memory | 8 KB |
|---|---|
| Flash Data Memory | 640 bytes |
| Primary ADC Resolution | 13 bits p‑p typical at +20 mV range, 20 Hz update rate |
| DAC Resolution | 12 bits |
| Normal Mode Power Consumption | 3 mA @ 3 V |
| Power‑Down Current | 20 pA (32 kHz crystal running) |
| Supply Voltage Range | 3 V or 5 V |
| Package | 52‑lead MQFP |
The ADuC816 operates from a single 3 V or 5 V supply.
The device includes 8 KB of on‑chip Flash/EE program memory.
The primary ADC provides 13‑bit peak‑to‑peak resolution typical at a +20 mV range with a 20 Hz update rate.
In normal mode the ADuC816 draws about 3 mA at 3 V.
