The 5B40 & 5B41 series modules are innovative low cost, high performance plug-in signal conditioners designed for industrial applications. These modules incorporate highly reliable transformer-based isolation and automated surface-mount manufacturing technology. They are compact, economical components that can satisfy various industrial applications.
The 5B40 and 5B41 series are low‑cost, compact signal‑conditioning modules that provide isolated analog input, amplification, filtering and protection. They offer 1500 V rms continuous isolation, +0.05% calibrated accuracy, and a 10 kHz bandwidth, making them suitable for industrial measurement applications such as temperature, pressure, flow and vibration monitoring.
The modules are hot‑swappable, mix‑and‑match compatible, and available with a variety of input ranges (e.g., -10 mV to +10 mV, -50 mV to +50 mV) and output ranges (e.g., -6 V to +5 V). They include built‑in anti‑aliasing filters, chopper‑stabilized amplifiers, and ESD protection, and meet hazardous‑area certifications (FM, CSA) and EMC directives.
| Bandwidth | 10 kHz |
|---|---|
| Isolation Voltage | 1500 V rms continuous |
| Accuracy | +0.05% calibrated |
| Input Protection | 240 V rms maximum |
| Temperature Range | -28°C to +85°C |
| Common‑Mode Rejection | 100 dB |
| Input Resistance | 200 MΩ |
| Noise | 0.4 µV rms |
| Input Range (5B40‑01) | -10 mV to +10 mV |
| Output Range (5B41‑01) | -6 V to +5 V |
Both modules provide a 10 kHz bandwidth, which is suitable for measuring rapidly varying signals.
The modules offer 1500 V rms continuous isolation between the input and output sides.
Yes, the series modules are mix‑and‑match and hot swappable, allowing insertion or removal without disrupting system power.
Available input ranges include -10 mV to +10 mV (5B40‑01), -50 mV to +50 mV (5B40‑02), and -100 mV to +100 mV (5B40‑03).
