The 5B32 isolated current input module is used for industrial signal isolation, filtering, and amplification. The module can measure 4-20mA or 0-20mA current input signals and convert them to a 0-5V voltage output. 5B32 series modules are hot-swappable and can be mixed and matched.
The 5B32 module provides isolated current input, amplification, protection, filtering and conversion of process‑current signals (4‑20 mA or 0‑20 mA) to a 0‑5 V output. It can withstand 240 V rms at the input terminals and is hot‑swappable, allowing insertion or removal without powering down the system.
Designed with transformer‑based isolation (1500 V rms continuous) and chopper‑stabilized low‑drift amplification, the module meets industrial standards for hazardous locations and electromagnetic compatibility, making it suitable for temperature, pressure, flow, rotation and other analog signal monitoring applications.
| Input Range | 0 mA to 20 mA or 4 mA to 20 mA |
|---|---|
| Output Range | -5 V to +5 V or 0 V to +5 V |
| Initial Accuracy @ +25 °C | 0.05 % Span + 0.05 % Iz’ |
| Nonlinearity | +0.02 % Span |
| Input Offset vs Temperature | 0.0025 % of IzPC |
| Gain vs Temperature | +0.0025 % of Reading/°C |
| Bandwidth (‑3 dB) | 4 Hz |
| Mechanical Dimensions | 2.275" × 2.375" × 0.595" (57.8 mm × 59.1 mm × 15.1 mm) |
| Power Supply Voltage | +5 V |
| Isolation Rating | 1500 V rms continuous |
It measures a process‑current input of 4‑20 mA or 0‑20 mA.
Yes, all 5B32 series modules are mix‑and‑match and hot swappable.
The module provides 1500 V rms continuous isolation.
Operating temperature range is –40 °C to +85 °C.
