AD7892 is a high speed, low power, 12-bit A/D converter that operates from a single +5 V supply. The part contains a 1.47 µs successive approximation ADC, an on-chip track/hold amplifier, an internal +2.5 V reference and on-chip versatile interface structures that allow both serial and parallel conn- ection to a microprocessor. The part accepts an analog input signal and converts it to a digital value.
The AD7892 is a high‑speed, low‑power 12‑bit analog‑to‑digital converter that operates from a single +5 V supply. It provides selectable input ranges (+10 V/+5 V, 0‑2.5 V, or +2.5 V) and features both parallel and serial output formats, making it suitable for microprocessor, microcontroller, and DSP applications.
The datasheet includes detailed specifications such as resolution, conversion time, power consumption, input/output pin functions, timing characteristics, and ordering information for the various AD7892 versions (A, B, S). It also provides guidelines for grounding, layout, and decoupling to achieve optimal performance.
| Resolution | 12 bits |
|---|---|
| Throughput Rate (AD7892‑3) | 600 kSPS |
| Power Consumption (typical) | 60 mW |
| Supply Voltage | +5 V (±5%) |
It operates from a single +5 V supply (±5%).
AD7892‑1 supports +10 V or +5 V, AD7892‑2 supports 0 V to +2.5 V, and AD7892‑3 supports +2.5 V.
Typical power dissipation is about 60 mW.
