The AD6640 is a high performance 12-bit analog-to-digital converter (ADC) that provides CMOS compatible digital outputs at 65 MSPS. The AD6640 operates on a single 5V supply and has an 80 dB spurious-free dynamic range (SFDR) over a bandwidth of 25 MHz. It is designed for use in multichannel, multimode receivers.
The AD6640 is a high‑speed 12‑bit analog‑to‑digital converter designed for IF sampling up to 70 MHz. It operates from a single 5 V analog supply and includes on‑chip track‑and‑hold, reference, and twos‑complement output.
The document provides full electrical specifications, pin descriptions, typical performance graphs, absolute maximum ratings, and ordering details for the 44‑lead LQFP package.
| Resolution | 12 Bits |
|---|---|
| Maximum Conversion Rate | 65 MSPS |
| Power Consumption | 710 mW (typical) |
| Analog Supply Voltage (AVcc) | 5.0 V |
| Differential Input Voltage Range | 2.0 Vp‑p |
| Signal‑to‑Noise Ratio (SNR) | 68 dB @ 2.2 MHz |
| Power Supply Rejection Ratio (PSRR) | 0.5 mV/V |
The AD6640 can sample at up to 65 MSPS.
Typical power consumption is 710 mW.
The converter provides 12‑bit resolution.
