The AD7908/AD7918/AD7928 are 8-channel, 1 MSPS, 8-/10-/12-bit ADCs with a sequencer. They feature fast throughput rate, low power consumption, flexible power/serial clock speed management, and a high-speed serial interface. These ADCs operate from a power supply of 2.7V to 5.25V and have a wide input bandwidth.
The AD7918 is a 10‑bit successive‑approximation ADC offering up to 1 MSPS throughput with low power consumption. It operates from a single 2.7 V to 5.25 V supply and features eight single‑ended inputs with a programmable channel sequencer.
The handbook includes detailed specifications, timing data, power‑vs‑throughput curves, serial interface information, and layout recommendations. Application hints cover grounding, decoupling, and PCB design to maximize performance.
| Resolution | 10 Bits |
|---|---|
| Maximum Throughput Rate | 1 MSPS |
| Supply Voltage Range | 2.7 V to 5.25 V |
| Normal Mode Operational Current | 2.7 mA max (5 V supply) |
| Input Voltage Range (single‑ended) | 0 to REF |
The AD7918 can sample at up to 1 MSPS.
In normal operational mode it draws up to 2.7 mA with a 5 V supply.
It operates from 2.7 V to 5.25 V.
