This datasheet provides details on the features and characteristics of the 1.6 V, Micropower 12-/10-/8-Bit ADCs AD7466/AD7467/AD7468.
The AD7468 is an 8‑bit successive‑approximation ADC that operates from a single 1.6 V to 3.6 V supply and delivers up to 320 kSPS throughput with low power consumption. The handbook provides functional block diagrams, detailed specifications, timing data, pin configurations and application guidance for battery‑powered and medical instrument designs.
The document also includes an ordering guide with part numbers for SOT‑23 and MSOP packages, as well as evaluation board information for system integration and testing.
| Supply voltage range | 1.6 V to 3.6 V |
|---|---|
| Resolution | 8 bits |
| Maximum throughput rate | 320 kSPS |
| Power consumption (normal mode, 3 V, 100 kSPS) | 0.57 mW max |
| Input capacitance | 20 pF typ |
The AD7468 operates from a single supply between 1.6 V and 3.6 V.
The device can sample up to 320 kSPS.
Typical power consumption is up to 0.57 mW.
