The AD8677 is a low offset voltage, high precision operational amplifier with a maximum offset voltage of 130 µV, 1.5 µV/°C maximum input offset drift, 0.25 µV p-p low noise, 115 dB maximum gain, CMRR and PSRR and 1.1 mA low supply current.
The AD8677 is a low‑offset, low‑noise operational amplifier offered in compact TSOT and SOIC packages. It features a maximum offset voltage of 130 pV, low bias currents of 1 nA, high CMRR and PSRR (≥115 dB), and operates from a wide supply range of +4 V to +18 V.
The datasheet provides detailed electrical specifications, absolute‑maximum ratings, typical performance curves, pin‑configuration diagrams, ordering information, and revision history for the device.
| Maximum Offset Voltage | 130 pV |
|---|---|
| Supply Current | 1.1 mA |
| PSRR (Power Supply Rejection Ratio) | 115 dB min |
| Gain Bandwidth Product | 0.6 MHz |
| Supply Voltage Range | +4 V to +18 V |
The AD8677 has a maximum offset voltage of 130 pV.
It operates from +4 V up to +18 V.
The device draws about 1.1 mA of supply current.
