The OP07D is a low power, high precision, ultralow offset voltage amplifier with low input bias current and high CMRR/PSRR. The device is packaged in a small DIP package and is specified for operation from ±5V to ±15V supply.
The OP07D precision op‑amp offers an ultra‑low offset voltage of 150 pV max, low input bias current (1 nA max) and low supply current (1.1 mA typical). It is designed for medical, industrial instrumentation, sensors, thermocouples, RTDs, strain bridges, shunt current measurements and precision filters, operating from +4 V to +18 V.
Key specifications include a high CMRR/PSRR of at least 115 dB, a gain‑bandwidth product of 0.6 MHz, a slew rate of 0.2 V/µs, and output voltage swing up to +4.1 V. The device is available in 8‑lead DIP and 8‑lead SOIC packages and is rated for operation from –40 °C to +125 °C.
| Maximum Offset Voltage | 150 pV |
|---|---|
| Input Bias Current | 1 nA max |
| Supply Current (typical) | 1.1 mA |
| Power Supply Rejection Ratio | 115 dB min |
| Common‑Mode Rejection Ratio | 115 dB min |
| Gain‑Bandwidth Product | 0.6 MHz |
| Slew Rate | 0.2 V/µs |
| Output Voltage Swing (positive) | +4.1 V |
The OP07D has a maximum offset voltage of 150 pV.
It operates from +4 V up to +18 V.
Typical supply current is 1.1 mA.
The gain‑bandwidth product is 0.6 MHz.
