The AD8657 is an 18V precision micropower CMOS RRIO operational amplifier with features such as micropower at high voltage, low offset voltage, single-supply and dual-supply operation, low input bias current, and gain bandwidth.
The AD8657 is a dual, micropower, precision rail‑to‑rail input/output amplifier optimized for low power and a wide supply voltage range. It operates from 2.7 V up to 18 V and features a typical quiescent supply current of 18 µA, 350 pV maximum offset voltage, and 20 pA low input bias current.
Designed for portable systems, current monitors, loop drivers, sensor front‑ends and wireless applications, the device is offered in 8‑lead MSOP and 8‑lead LFCSP packages and is rated for –40 °C to +125 °C operation.
| Supply Voltage Range | 2.7 V to 18 V |
|---|---|
| Typical Quiescent Supply Current | 18 µA per amplifier |
| Input Offset Voltage | 350 pV max |
| Input Bias Current | 20 pA typical |
| Gain Bandwidth Product | 200 kHz typ |
| Operating Temperature Range | –40 °C to +125 °C |
| Package Types | 8‑lead MSOP, 8‑lead LFCSP |
The AD8657 operates from 2.7 V up to 18 V.
The device has a maximum input offset voltage of 350 pV.
It is offered in an 8‑lead MSOP package and an 8‑lead LFCSP package.
Typical quiescent supply current is 18 µA per amplifier.
