ADA4091-2 is a dual, micropower, single-supply, 1.2 MHz bandwidth amplifier featuring rail-to-rail inputs and outputs. It is guaranteed to operate from a +3 V single supply and operates over a wide input voltage range. Low offset voltage, low noise, low power.
The ADA4091-2 is a dual, micropower, single‑supply operational amplifier with rail‑to‑rail input and output capability. It operates from 3 V to 36 V, offers a low supply current (250 pA per amplifier) and a wide bandwidth of 1.2 MHz.
Typical applications include industrial process control, battery‑powered instrumentation, power‑supply control and protection, and telecommunications. The device is supplied in an 8‑lead narrow‑body SOIC package and is rated for operation from –40 °C to +125 °C.
| Supply Voltage (max) | 36 V |
|---|---|
| Gain‑Bandwidth Product | 1.22 MHz |
| Power Supply Rejection Ratio | 100 dB |
| Package | 8‑lead narrow‑body SOIC (R‑8) |
It can operate from a single supply of 3 V up to 36 V, or from dual supplies of ±15 V.
It is offered in an 8‑lead narrow‑body SOIC (R‑8) package.
