The document introduces the ADCMP606/ADCMP607 two types of comparator products, which have full range power supply range, low power consumption, high speed, CML compatible output and other features, suitable for high-speed instrumentation, clock and data signal restoration, logic level shifting or translation, pulse spectroscopy, high-speed line receivers, threshold detection, peak and zero crossing detectors, high-speed trigger circuit, pulse-width modulator, current / voltage-controlled oscillator, automatic test equipment (ATE) and other applications
The ADCMP606 and ADCMP607 are ultra‑fast, rail‑to‑rail, single‑supply CML comparators from Analog Devices. They operate from 2.5 V to 5.5 V supply, provide 1.25 ns typical propagation delay, and include features such as shutdown control, programmable hysteresis (ADCMP607) and a CML‑compatible output stage.
The document contains detailed electrical characteristics, timing diagrams, absolute maximum ratings, thermal resistance data, pin‑out tables for the 6‑lead SC70 (ADCMP606) and 12‑lead LFCSP (ADCMP607) packages, and typical performance curves useful for designers of high‑speed instrumentation, data‑recovery, and pulse‑width modulation circuits.
| Supply Voltage Range | 2.5 V to 5.5 V |
|---|---|
| Propagation Delay (typical) | 1.25 ns |
| Power Dissipation (2.5 V) | 30 mW |
| Input Common‑Mode Range | –0.2 V to VCC + 0.2 V |
| Hysteresis Adjustment Range | up to 120 mV |
| Maximum Operating Temperature | –40 °C to +125 °C |
The ADCMP607 has a typical propagation delay of 1.25 ns.
The ADCMP606 can operate with a supply voltage from 2.5 V to 5.5 V.
The ADCMP607 is offered in a 12‑lead LFCSP package.
Both devices are rated for operation from –40 °C up to +125 °C.
