ABB drives control the compressors of the world's longest gas export pipeline
This document describes ABB's MEGADRIVE‑LCI variable speed drive system supplied for the Ormen Lange offshore gas field compressors. It details the drive configuration, including a four‑winding transformer, filter system, 12‑pulse converter and a 48 MW synchronous motor, and presents the main technical data of the system.
The brochure also outlines the benefits of using electric variable speed drives for large compressors—high reliability, low maintenance, high efficiency and reduced emissions—and summarizes the extensive testing performed at ABB’s facilities to verify performance, efficiency and compliance with customer specifications.
| Power system voltage | 132 kV / 50 Hz |
|---|---|
| Shaft power | 48 MW |
| Shaft speed (nominal / max) | 3500 / 3780 rpm |
| Voltage per winding | 6700 V |
| Current | 2325 A |
| Cooling method | Air‑to‑water / TEWAC |
| Control speed range | 2520 – 3780 rpm |
| Control shaft‑power range | 16 – 48 MW |
| Pipeline diameter | 42 – 44 inches (1.1 m) |
ABB supplied three MEGADRIVE‑LCI variable speed drive systems for the Ormen Lange compressors.
The pipeline diameter is 42 – 44 inches (approximately 1.1 metre).
