This document is a system board user's manual that contains copyrighted information. No part of it may be reproduced in any form or used to make any transformation/adaptation without prior written permission from the copyright holders. This manual is provided for informational purposes only. The manufacturer makes no representations or warranties with respect to the contents or use of this manual and specifically disclaims any express or implied warranties of merchantability or fitness for any particular purpose. The user assumes the entire risk of using this document or the results of its use. Furthermore, the manufacturer reserves the right to revise this publication and make changes to its contents at any time, without obligation to notify any person or entity of such revisions or changes.
This manual provides safety and handling instructions for the X48‑T3RS system board, including warranty information, electro‑static discharge precautions, and required tools for installation. It also lists the package contents and outlines the steps for preparing the system before mounting the board.
The document details the hardware specifications such as the LGA 775 processor socket, Intel X48 Express chipset, DDR3 memory support, PCI Express expansion slots, audio codec, and Gigabit LAN controller. BIOS features, jumper settings, and rear I/O ports are also described to help users configure the board correctly.
| Processor socket | LGA 775 |
|---|---|
| Supported CPUs | Intel Core2 Quad and Duo |
| Front Side Bus | 800/1066/1333/1600 MHz |
| Chipset | Intel X48 Express |
| Southbridge | Intel ICHIR |
| Memory slots | 4 × 240‑pin DDR3 DIMM |
| Memory types | DDR3 800/1066/1333/1600 MHz |
| Maximum memory | 8 GB |
| Audio codec | Realtek ALC885 8‑channel HD Audio |
Keep the board in its anti‑static bag until installation, wear an antistatic wrist strap, work on a static‑free surface and handle the board only by its edges.
The warranty is void if the product is subjected to physical abuse, improper installation, modification, accidents, or unauthorized repair.
