This document is the copyright statement and usage instructions for 75300331 Rev. A+ System Board User’s Manual. The document provides information about the features and characteristics of the product.
This manual covers the hardware installation steps for the ASUS System Board Rev. A+, including CPU mounting, memory installation, and connector wiring. It also details the Award BIOS Setup Utility, supported software, and system management features.
Additional sections provide troubleshooting guidance, safety warnings, and regulatory information to help users diagnose common problems such as power issues, display errors, and peripheral failures. This manual is written in Chinese.
| Chipset | nVIDIA nForce2 Ultra 400 |
|---|---|
| CPU Socket | Socket A for PGA processors |
| Memory Support | Up to 3 GB DDR SDRAM (PC1600, PC2100, PC2700, PC3200) |
| Expansion Slots | 1 AGP slot, 5 PCI slots |
| LAN Interfaces | nVIDIA nForce2 MCP‑T/ICS1893 PHY (10/100 Mbps) and Realtek RTL8110S Gigabit LAN (10/100/1000 Mbps) |
| USB Ports | USB 2.0 and USB 1.1 |
The board includes one AGP slot and five PCI slots.
It supports up to 3 GB of unbuffered DDR SDRAM, compatible with PC1600, PC2100, PC2700 and PC3200 modules.
