This manual covers the complete setup of the TCL HD21M62US television, including unpacking, base installation, and connection of video and audio sources. Detailed diagrams show how to attach the base, align the mounting holes, and rotate the base into place.
It also explains basic and advanced operation such as power on/off, channel selection, picture and sound adjustments, aspect‑ratio switching, and built‑in functions like program guide and calendar. A troubleshooting section lists common issues and step‑by‑step checks to resolve them. This manual is written in Chinese.
| Power Consumption | 85W |
|---|---|
| Input Voltage | 220V~50Hz |
| Video Input Level | 10Vpp |
| Audio Input Level | 5V RMS |
| Supported Resolution | 1920x1080 60Hz |
Press the “画面比例” key on the remote to toggle between the 16:9 and 4:3 display modes.
The television consumes 85 W of power.
