SyncMaster 933BW/933GW LCD monitor user manual, introduces product safety instructions, installation, cleaning and other content
This manual covers safety precautions, proper handling, installation steps, and cleaning methods for the Samsung SyncMaster 933BW/933GW 19‑inch LCD monitor. It includes detailed guidance on power safety, mounting, VESA‑compatible brackets, and recommended usage posture.
The document also lists the complete specifications of the display, packaging contents, initial setup procedures, and contact information for Samsung service centers worldwide. This manual is written in Chinese.
| Display size | 19 inches (48 cm) |
|---|---|
| Display area | 40.824 cm × 25.515 cm |
| Dot pitch | 0.2835 mm (horizontal) × 0.2835 mm (vertical) |
| Horizontal sync frequency | 30 ~ 81 kHz |
| Vertical refresh rate | 56 ~ 75 Hz |
| Color depth | 16.7 million colors |
| Native resolution | 1440 × 900 @ 60 Hz |
| Maximum resolution | 1440 × 900 @ 75 Hz |
| Input signals | RGB analog, DVI digital |
| Maximum pixel clock | 137 MHz |
| Power supply | AC 100‑240 V, 50/60 Hz |
| Dimensions (without stand) | 45.1 × 33.17 × 7.24 cm |
| VESA mounting interface | 75 mm × 75 mm |
Use a slightly damp soft cloth to wipe the screen; do not spray cleaning agents directly onto the surface.
Yes, the monitor supports a 75 mm × 75 mm VESA mounting interface; use the appropriate screws and follow the installation instructions.
Set the computer to DPM (Display Power Management) and enable the screen saver in active mode.
