This manual explains how to install the ES-701T, including proper grounding, water‑inlet and drain‑pipe connections, and placement on a level floor. It also covers the steps for loading laundry, selecting water flow, wash time, and spin time, as well as cleaning and maintenance procedures.
Additional sections describe safety precautions, emergency handling, troubleshooting common problems, and the machine’s technical specifications such as voltage, power consumption, dimensions and weight. This manual is written in Chinese.
| Rated Voltage | 110 V |
|---|---|
| Rated Frequency | 60 Hz |
| Standard Water Capacity | 602 L |
| Power Consumption (Wash) | 370 W |
| Power Consumption (Spin) | 160 W |
| Dimensions (W×D×H) | 900 mm × 490 mm × 920 mm |
| Weight | 32 kg |
Connect the grounding wire to the grounding rod; do not attach it to a power outlet or other fixtures.
Check that the drain pipe is not too high, not too narrow, and not excessively long; adjust its position or replace it if necessary.
The machine measures 900 mm wide, 490 mm deep, and 920 mm high, and it weighs 32 kg.
