Haier FCD-8 / FCD-M8 is an induction cooker produced by Haier.
This manual covers the complete setup and use of the Haier FCD-8 and FCD-M8 electric water heaters. It includes a packing list, safety precautions, and detailed installation steps for wall‑mounting the unit, as well as instructions for initial water filling and power connection.
Operating instructions describe how the heater maintains water temperature, with the FCD-8 fixed at 60 °C and the FCD-M8 offering adjustable settings between 30 °C and 75 °C. The guide also explains the built‑in leakage protection test, troubleshooting of common issues, and maintenance recommendations. This manual is written in Chinese.
| Rated Voltage | 220 V, 50 Hz |
|---|---|
| Rated Pressure | 0.75 MPa |
| Minimum Water Pressure | 0.05 MPa |
| Dimensions (W×H×D) | 325 mm × 414 mm × 1000 mm |
| Temperature Setting (FCD‑8) | Fixed 60 °C |
| Temperature Setting (FCD‑M8) | Adjustable 30 °C – 75 °C |
Press the test button 1‑2 times each month; the reset button will pop up, indicating the protection is working, then press the reset button to resume normal use.
