This manual covers safety precautions, installation procedures, and proper wiring for the Sampo AW series split‑type air conditioners. It details required clearances, grounding, and the correct handling of the Y‑type power cord.
The guide also explains how to set temperature, select operating modes, and use timer functions. A specification table lists key performance data such as IP ratings and power consumption for each model. This manual is written in Chinese.
| IP Rating (Indoor) | IP X0 |
|---|---|
| IP Rating (Outdoor) | IP X4 |
A minimum indoor clearance of 50 cm is required.
A minimum outdoor clearance of 100 cm is required.
If the Y‑type power cord is damaged, contact Sampo service personnel for replacement; do not replace it yourself.
