The AVC-A11SR is an AV surround amplifier with features such as THX Cinema, Home Pure Direct, and Pure Digital Surround.
This manual introduces the Denon AVC-A11SR digital surround amplifier, covering safety precautions, handling warnings, and an overview of its features such as dual 32‑bit DSP processing, THX certification, and support for Dolby Digital, DTS and other surround formats. It also explains the unit’s power specifications, speaker configurations, and optional dual‑surround speaker mode.
Detailed sections guide you through proper installation, including required clearances for heat dissipation, wiring of audio and video inputs/outputs, remote‑control setup, and troubleshooting tips. Follow the step‑by‑step instructions to ensure reliable operation and optimal sound performance.
| Power Output per Channel | 125 W into 8 Ω |
|---|---|
| Number of Power Amplifiers | 7 |
| Video Component Inputs | 3 sets of component video (Y, R‑Y, B‑Y) |
| Channel I/O | Eight channel inputs & outputs (7.1 system) |
Do not expose the unit to rain or moisture, keep ventilation openings clear, and avoid placing foreign objects inside the chassis.
Leave at least 10 cm of clearance on the top, back and sides of the unit.
Each channel is rated at 125 watts into an 8‑ohm load.
The amplifier offers eight channel inputs and outputs, supporting a 7.1‑channel configuration.
