This is a manual for a flat TV, including the TV's features, appearance design, and usage instructions.
The manual covers the basic installation and operation of Philips flat-screen televisions, including safety notices, dimensions, and power requirements. It also describes the available video input options and how to configure them.
Detailed sections explain VGA resolution settings, RS232 communication, menu navigation, and specifications for different screen sizes. The document includes diagrams and tables for quick reference during setup and maintenance.
| VGA resolution (640x480) | 60, 72, 75, 85 Hz |
|---|---|
| VGA resolution (848x480) | 60 Hz |
| VGA resolution (852x480) | 60 Hz |
| MAC resolution (640x480) | 66.67 Hz |
| MAC resolution (1024x768) | 74.93 Hz |
| SVGA resolution (800x600) | 56, 60, 72, 75, 85 Hz |
| XGA resolution (1024x768) | 60, 70, 75, 85 Hz |
| SXGA resolution (1280x1024) | 60, 72 Hz |
| Power input voltage | 10 V–240 V |
| Frequency | 50/60 Hz |
| Dimensions (32‑inch model) | 96.4 × 51.2 × 8.9 cm |
| Dimensions (42‑inch model) | 121 × 66 × 9 cm |
The TV supports multiple VGA resolutions, including 640×480 at 60‑85 Hz, 848×480 at 60 Hz, 852×480 at 60 Hz, and higher modes such as SVGA 800×600 and XGA 1024×768.
The TV includes an RS232 port for serial communication; connect the computer’s RS232 cable to the TV’s RS232 connector and use the documented command set.
The 32‑inch model measures 96.4 × 51.2 × 8.9 cm, while the 42‑inch model measures 121 × 66 × 9 cm.
The TV can be powered from 10 V up to 240 V AC.
