This document is about the CNC 8035 PRELIMINARY operation manual from Fagor Automation. The document includes the introduction of the product, version history, safety conditions, warranty conditions, etc. The operation manual covers aspects such as manual mode operation, machining operation, and cycle operation.
This manual from Fagor Automation covers the CNC 8035 controller, describing its hardware layout, connection options, and basic operation procedures. It includes details on power requirements, RS‑232 communication, and the supported software version.
Additional sections address optional software features (SOFT V16.3x) and provide reference tables for troubleshooting and maintenance tasks.
| Communication Interface | RS‑232 |
|---|---|
| Power Supply | 5 V and 24 V |
The manual references software version V16.3x.
It uses an RS‑232 serial port.
