This service manual provides detailed information for the 8035 T CNC machine, including DNC communication setup, program generation steps, coordinate system definitions, and tool radius compensation methods. It also describes path control functions, canned cycles, probing, and additional utility features.
The final sections give safety guidelines and cleaning instructions for the control panel and machine components, ensuring proper maintenance and safe operation. This manual is written in Japanese.
| Feed rate units | MM/MIN or INCHES/MIN (G94) |
|---|---|
| Feed per rev units | MM/REV or INCHES/REV (G95) |
| Spindle speed unit | RPM |
| Tool radius compensation numbers | 640, 6G41, 6G42 |
Use a soft cloth dampened with water or alcohol, avoiding abrasive particles, and do not use compressed air.
First disconnect power and ensure the CNC power source is isolated before performing any maintenance.
