This manual introduces the functions and use of BT-MC S1005M1106-H.
The Panasonic BT-LH1700WMC is a color LCD video monitor designed for broadcast and business use, with a 17.1-inch widescreen panel. It accepts SDI, VIDEO, Y/C, and YPbPr/RGB signals, supports NTSC and PAL, and can divide the screen into two windows or show WFM in one window.
The manual covers front and rear controls, on-screen menu operation, saving and loading user data, external GPI or RS232C control, AC or 11–17 V DC power, rack installation, error displays, maintenance, servicing checks, and specifications. It also identifies the BTYAE1700G embedded audio unit and BTMA1710G rack-mounting adaptor as optional accessories. This manual is written in Chinese.
| Display size | 17.1 inches |
|---|---|
| Aspect ratio | 15:9 |
| Resolution | 1280 × 768 (WXGA) |
| Color count | Approximately 16,700,000 |
| Viewing angle | 176° up/down and 176° left/right |
| Supported television systems | NTSC and PAL |
| External DC input | 11–17 V DC |
| Dimensions with support stand | 430 × 323.5 × 198 mm |
It supports SDI with HD/SD compatibility, VIDEO, Y/C, and YPbPr/RGB inputs.
Yes. It can split the display into two windows when both use the same input terminal and format.
The optional BTYAE1700G embedded audio unit must be installed.
Five groups of picture-adjustment values can be saved and loaded as user data.
