EIZO L797 Color LCD Monitor User Manual

About this manual

This manual explains how to safely install and operate the EIZO L797 color LCD monitor. It includes safety symbols, precautions for handling, and detailed wiring instructions for D‑Sub, DVI, and ADC connectors.

The guide also covers the ScreenManager software, adjustment of picture settings, energy‑saving features, mounting options, troubleshooting, cleaning, and a full list of technical specifications. This manual is written in French.

What's inside

• Precautions and Safety
• Cable Connection
• ScreenManager Software
• Picture Settings and Adjustment
• Energy‑Saving Configuration
• USB Bus Usage
• Mounting Bracket Installation
• Troubleshooting
• Cleaning
• Specifications

Specifications

Frequently asked questions

How do I connect the monitor to a computer using a D‑Sub or DVI connector?

Use the signal cable described in section 2‑2 of the manual to connect the D‑Sub or DVI connector on the monitor to the computer.

Can I mount the monitor on a wall or bracket?

Yes, the manual provides instructions for fixing a support arm and adjusting the tilt bracket; follow the mounting section (chapter 6).

What power settings are recommended for energy saving?

Use the Energy‑Saving configuration described in chapter 4‑4 to reduce power consumption when the monitor is idle.
