This is a user manual that provides instructions on how to use products distributed by Yamaha-Kemble Music (U.K.) Ltd., as well as important information on connecting the plug and cord.
This manual covers safety notices and compliance information for the MW10, including wiring instructions for the mains plug (blue = neutral, brown = live) and power‑supply details such as 48 V phantom power. It also describes the device’s audio and USB connections, including the 2TR IN/USB and USB Audio CODEC interfaces.
Installation steps guide users through setting up the MW10 with Steinberg Cubase LE on Windows and Mac, configuring the ASIO Multimedia Driver, selecting the appropriate USB Audio CODEC, and using the MIDI and device‑setup menus. Troubleshooting tips and technical specifications are provided at the end of the document.
| Mains wiring colour code | BLUE = NEUTRAL, BROWN = LIVE |
|---|---|
| Audio input | 2TR IN/USB (ST/TO C‑R) |
| USB audio interface | USB Audio CODEC (1) and (2) |
Connect the blue wire to the neutral (N) or black terminal and the brown wire to the live (L) or red terminal; do not connect either wire to the earth terminal.
Use the supplied USB cable and select the USB Audio CODEC interface in the operating system’s audio settings or within Cubase LE.
