ASRock A780FullDisplayPort Motherboard User Manual

ASRock A780FullDisplayPort User Manual

Brand: ASRock
Category: Motherboard
Document type: User Manual
Language: English
Pages: 64
File format: PDF
File size: 1.5 MB
Published: 15 March, 2012
Updated: 30 September, 2023
Model: A780FULLDISPLAYPORT
MD5 checksum: 935AF00D4D08BDADA5BC9EE724799BB0
PDF: ASRock A780FullDisplayPort Motherboard User Manual PDF

About this manual

This manual covers everything needed to install and configure the ASRock A780FullDisplayPort motherboard, including hardware requirements, CPU and memory installation, and detailed BIOS configuration. It also lists the supported operating systems, drivers, and utilities provided on the support CD.

Safety warnings, overclocking guidelines, and troubleshooting tips are included, along with specifications for the chipset, expansion slots, I/O ports, and the optional DisplayPort card. The document ends with contact information for technical support.

What's inside

Introduction
Specifications
Installation
BIOS Setup Utility
Software Support
Hardware Layout
Expansion Slots
Audio and Video
Security

Specifications

Form Factor	Micro ATX (9.6‑in x 9.6‑in)
CPU Socket	Socket AM2+ / AM2
Chipset	Northbridge AMD 780G, Southbridge AMD SB700
SATA Connectors	6 × SATAII 3.0 Gb/s ports with RAID, NCQ, AHCI, Hot‑Plug
Video Outputs	D‑Sub, DVI‑D, HDMI, DisplayPort

Frequently asked questions

Which operating systems are supported by this motherboard?

The motherboard supports Microsoft Windows XP, XP Media Center, XP 64‑bit, Vista and Vista 64‑bit.

How many SATA ports does the A780FullDisplayPort have?

It provides six SATAII 3.0 Gb/s connectors that support RAID, NCQ, AHCI and hot‑plug functions.

What video output options are available on the board?

Four video outputs are provided: D‑Sub, DVI‑D, HDMI and DisplayPort (via the optional DisplayPort card).
