ASRock 785GM-GS3 / 785GM-S3 is a motherboard from ASRock. It uses the 785G chipset and supports AMD Athlon II processors.
The guide introduces the ASRock 7Z95GM7‑GS3 / Z85GM7‑S3 Micro‑ATX motherboard, its supported AMD Phenom II, Athlon II and Sempron CPUs, and dual‑channel DDR3 memory up to 1800 MHz. It details the layout of expansion slots, including one PCI‑Express x16, one PCI‑Express x1 and two PCI slots, as well as integrated AMD Radeon HD 4200 graphics.
Connectivity options cover Realtek RTL8111 Gigabit LAN, Realtek ALC662 high‑definition audio, four SATA 3.0 Gb/s ports with RAID 0/1/10/JBOD support, and multiple USB 2.0 headers. The manual also explains BIOS features, power‑saving technologies, and safety/compliance information such as FCC, CE and RoHS certifications. This manual is written in Chinese.
| Maximum memory | 12 GB |
|---|---|
| PCI slots | 2 × PCI |
| LAN controller | Realtek RTL8111, 10/100/1000 Mbps |
Yes, it supports RAID 0, RAID 1, RAID 10 and JBOD.
It uses a Realtek RTL8111 Gigabit Ethernet controller.
