ASRock K10N78hSLI-WiFi / K10N78hSLI-1394 Motherboard
This Quick Installation Guide introduces the ASRock K10N78hSLI‑WiFi / K10N78hSLI‑1394 motherboard, its ATX form factor, supported CPUs, memory and expansion slots, and provides step‑by‑step installation instructions. It also points to the full user manual on the support CD for detailed configuration.
Key features covered include the layout of connectors (USB, SATA, PCI‑Express, HDMI/SPDIF, LAN, IEEE‑1394), audio and video options, the built‑in Wi‑Fi‑802.11g module, and BIOS utilities such as the OC Tuner and Intelligent Energy Saver.
| CPU Socket | AM2 940‑Pin |
|---|---|
| Supported CPUs | AMD AM2/AM2+ (Phenom, Athlon 64, Sempron) |
| Chipset | NVIDIA GeForce 8200 |
| Memory Slots | 4 x DDR2 DIMM slots |
| Maximum Memory Capacity | 8 GB |
| SATAII Connectors | 6 x SATAII 3.0 Gb/s (RAID, NCQ, AHCI) |
| LAN | Gigabit LAN 10/100/1000 Mb/s (Realtek RTL8211B) |
| Wireless Module | ASRock WiFi‑802.11g, 54 Mbps (802.11g) / 11 Mbps (802.11b) |
The board supports up to 8 GB of DDR2 memory across its four DIMM slots.
There are six SATAII 3.0 Gb/s connectors that support RAID, NCQ and AHCI.
The ASRock WiFi‑802.11g module supports IEEE 802.11g at up to 54 Mbps and IEEE 802.11b at up to 11 Mbps.
It uses an AM2 940‑Pin socket compatible with AM2 and AM2+ processors.
